VITAL SIGN MONITOR

Brand : Medworld Electronics
Model : VS3

Features:
 Simple and convenient operation, which is applicable for community medical treatment and
family etc.
 4.3 inch color TFT display and highlight LED display
 Adjustable audible and visual alarms
 Built-in rechargeable lithium battery for uninterrupted monitoring

TECHNICAL SPECIFICATIONS:

SPO2
 Measuring Range: 0 ~ 100 %
 Resolution: 1%
 Accuracy: 70% ~ 100% (±2 %)

 Pulse Rate: 20-250 BPM
 Resolution: 1 BPM
 Accuracy: ±3 BPM

NIBP
 Method: Oscillometry
 Measure mode: Manual, Auto, STAT
 Unit: mmHg, kPa
 Measure and alarm range:
 Adult Mode
 SYS 40 ~ 280 mmHg
 DIA 10 ~ 225 mmHg
 MEAN 20 ~ 240 mmHg
 Pediatric Mode
 SYS 40 ~ 220 mmHg
 DIA 10 ~ 160 mmHg
 MEAN 20 ~ 170 mmHg
 Neonatal Mode
 SYS 40 ~ 135 mmHg
 DIA 10 ~ 100 mmHg
 MEAN 20 ~ 110 mmHg
 Resolution: 1mmHg
 Accuracy: ±5mmHg

TEMPERATURE:
 Measuring range: 32-42.9 ℃
 Accuracy:
 ±0.2℃ (35-42℃)
 Working voltage: DC 3.0V Battery AAA*2)
 Humidity≤85%,RH

 Measuring distance: 0-5CM
Standard Parameters:
 NIBP, SPO2, PR, TEMP

Packing:
 Single package size: 35 *25 *26cm
 Single gross weight: 3 KG
 8 unit per carton, package size: 72.5 *53 *56.5 cm, total gross weight 22 KG
